The white Bose Professional FreeSpace DS 40F is a flush-mount passive loudspeaker with a single 4.5" full-range driver and a 125° conical coverage pattern for intelligible foreground/background music and speech reproduction in retail stores, restaurants, resorts, and more.
It handles up to 40W continuous (160W peak) and is capable of producing a maximum peak SPL of 109 dB. The DS 40F utilizes an integrated multi-tap transformer, which can be configured for an array of 70V/100V settings via a convenient thumbwheel beneath the grille.
The DS 40F is voiced to ensure consistent tonality throughout the FreeSpace DS family, so it can be installed alongside DS 16 and DS 100 loudspeakers without compromising the system's sonic signature. Installation options (available separately) include ceiling-mount brackets, adjustable tile bridges, pendant-mount kits, and square grilles.
Ideal for use in retail stores, restaurants, concourse, transportation facilities, resorts, hospitality venues, houses of worship, and ballrooms
Full-range loudspeaker with a single 4.5" driver in a ported enclosure
Delivers a 125° conical coverage pattern and foreground/background music and speech reproduction for flush-ceiling or pendant-mount applications
Frequency range (-10 dB) down to 70 Hz
Maximum SPL of 103 dB (continuous) / 109 dB (peak)
Integrated multi-tap transformer with innovative thumb wheel adjustment for easy-to-change tap setting from underneath the loudspeaker grille
Shared voicing across entire FreeSpace DS product family enables DS 16, DS 40, and DS 100 loudspeakers to be integrated on the same system and maintain consistent tonal quality
Shortcan design allows installation in shallower ceilings with a minimum depth of 6.4"
Supported by a suite of optional accessories—ceiling-mount bracket, adjustable tile bridge, pendant-mount kit, and square grille
