The CDi Series amplifiers are professional tools designed and built for installed sound applications. The series includes four models which are identical except for output power: CDi 1000, CDi 2000, CDi 4000, and CDi 6000. All are rugged and lightweight, and offer unmatched value in their class.
Features
Extremely versatile; rated for 2-, 4-, 8-ohm loads and 70V and 140V outputs.
Switch-mode universal power supply.
Intuitive front-panel LCD screen for quick, easy configuration.
Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting.
Up to 20 user defined DSP presets are available.
Specifications
Channels |
2 |
Sensitivity (for full rated power at 8 ohms) |
1.4V |
Rated Power Output (per channel @ 4 ohms) |
500W Stereo |
Signal to Noise Ratio (below rated 1 kHz power at 8 ohms) |
100 dB (A-weighted) |
THD |
< 0.5% |
Damping Factor (20 Hz to 400 Hz) |
> 500 |
Frequency Response (at 1W, 20 Hz - 20 kHz) |
+ 0 dB, -1 dB |
Crosstalk (below rated power) 20 Hz to 1 kHz |
>70 dB |
Input Impedance (nominal) |
20k ohms balanced, 10k ohms unbalanced |
Dimensions |
3.5" x 19" x 12.25" |
Weight |
22.0 lbs |
IEC Power Connector |
15A |
