product description

Speaker Type:

2-way, rear side open

Tweeter:

 1- inch cloth dome

Woofer:

 2 x 5.25-inch aluminum cone

Crossover Frequency:

2,200 Hz

Frequency Response:

45 to 20,000 Hz

Sensitivity:

86 db at 2.83 v/1m

Recommended amplifier power:

30 to 120 wpc

Nominal/peak power handling:

50 / 120 wpc

Nominal impedance:

 6 Ω

Finish:

Soft Paint Black Baffle

Grille:

Metal Magnetic Paintable

Accessories included:

Cutout template, manual

Dimensions (H/W/D):

Height: 7.4 in in / 188.3 mm – Width: 17.7 in / 448.3 mm – Depth: 3.4 in / 85.6 mm

Cut-out Dimensions:

Height: 6.2 in / 157 mm – Width: 16.4 in / 417 mm

Mounting depth:

3.3 in/ 84 mm
