Featuring a 6.5” Injection Molded Graphite (IMG) Woofer and 1” Pivot Aluminum Dome ABS Tractrix® Horn-Loaded Tweeter, the PRO-16RW brings incredible acoustics with the signature Klipsch sound. Featuring the SecureFit™ Installation System, the Klipsch Professional Series Reference speakers are the ideal choice for custom home installation audio.
SECUREFIT™ INSTALLATION SYSTEM
The exclusive modular installation system allows for the dog legs to be engaged by hand to a preset clamping force, eliminating the possibility of overtorquing. The speaker module is fixed to the bezel using machine screws instead of traditional drywall screws for a more robust, acoustically stable installation.
CONTROLLED DISPERSION™ TECHNOLOGY
Controlled Dispersion™ Technology allows for the tweeter to be aimed up to 15° in any direction. This provides the perfect on-axis frequency response to off-center listening positions and the ideal solution for challenging installation positions.
ALL NEW, BEZEL-FREE MAGNETIC GRILLE
A completely redesigned powder coated magnetic steel grille eliminates the bezel for seamless, pristine integration into the living space.
Features:
6.5” Injection Molded Graphite (IMG) Woofer
1” Pivot Aluminum Dome ABS Tractrix® Horn-Loaded Tweeter
Exclusive, modular SecureFit™ Installation System
Bezel-Free square and round paintable magnetic grilles
Controlled Dispersion™ Technology
Magnetic paint shield
Frequency Range |
63Hz - 23kHz +/- 3dB |
High Frequency Driver |
1" (2.54cm) Aluminum Dome Tweeter mated to a 90°x90° Tractrix® Horn |
Low Frequency Driver |
6.5" (16.51cm) IMG Woofer |
Sensitivity |
93 dB @ 2.83V / 1m |
Coverage Angle |
90° x 90° |
Power Handling |
50W RMS / 200W Peak |
Impedance |
8 Ohm Compatible |
Enclosure Type |
ABS/Infinite Baffle |
Finish |
Black Baffle/Frame, White Paintable Grille |
Product Dimensions |
9.0” W x 14.1” H x 3.9” D (22.8cm W x 35.8cm H x 9.8cm D) |
Mounting Depth |
3.78” (9.6cm) |
Cutout Dimensions |
13” H X 8” W (33.0cm H X 20.3cm W) |
Product Weight |
7.2lbs (3.25kg) |
Included |
Flat Magnetic Grille, Paint Shield |
Installation Kit |
IK-650-W II or IK-650-W (Sold Separately) |
Fire Rated Enclosure |
ME-650-W (Sold Separately) |
Built From |
2017 |
